Safety Risk Management in Research - Part 2 of 8
Michael Heald • Dec 23, 2019
Risk Mañana (noun): The temptation to leave risk management until is it impossible to ignore. Invest in an early dry run and enjoy the benefits.
Risk management is not just something to worry about during development, it lives on through launch and right up until the last product has been used after it has been taken off the market. Decisions made early in development about risk scoring and evaluation live with the product, and the manufacturer must stand by those decisions the entire time that the product is on the market. If the risk bar is set too low to expedite development for the sake of a launch date, imagine having to defend it when people get hurt by an under-developed product on the market? Set it too high and costly over-engineering or even project failure may result.
The aim of risk management is to ensure that the risk of using a device is always outweighed by the benefits of using the device – a simple enough concept. As development marches on, risk assessments are made to ensure that the device remains on the benefit side of the benefit-risk balance, but where is that tipping point for a specific product? If it is mis-judged because someone had to make some hurried decisions to get the risk management plan out, the consequences of subsequent rework and back-peddling could be very painful.
So, when can you test and refine your risk scoring and evaluation system before committing to it in development? In the research stage of course. During concept development, or bought-in platform device selection, it is the perfect time to size scoring systems and test your benefit-risk tipping point. Apart from providing an opportunity to calibrate your risk management set-up, risk profiling should be central to the concept/buy-in selection strategy anyway. One of the responsibilities of the device engineering team should be to make sure that bought-in device selection for development is not just device Tinder; it should be the result of objective assessment, including risk profiling.
An interesting parallel to bough-in device selection is when a pharmaceutical generics manufacturer is selecting a branded drug to copy as a generic. Sometimes the branded drug is marketed with a delivery device, the design of which which may be rather old by the time the drug patent is expired. In order to market the generic version of the drug the manufacturer often has to ensure that the generic drug delivery device looks-like and works-like the branded one. Here is the dilemma for the device development team, because the risk bar for development of the generic device must be set to reflect current state-of-the-art safety levels. Consequently, the device team can have an important role to play in any decision to develop a generic version of a branded combination product.
